ISA 90X90X8 Steel Angles

Get a Price/Quote

MOQ : 100 Kilograms

ISA 90X90X8 Steel Angles Specification

Coating Type
Plain or can be hot-dip galvanized upon request

Product Form
Bar / Angle

Material Composition %
C: 0.23%, Mn: 1.50%, P: 0.045%, S: 0.045%, balance Fe

Heat Resistance
Yes

Corrosion Resistant
Moderate, can be enhanced by coating

Size
90 mm x 90 mm x 8 mm

Recyclable
Yes, 100%

Tensile Strength
410 - 540 MPa (Approximate, depending on grade)

Hardness
120-180 HB (Brinell)

Diameter
Not applicable (angle bar)

Product Name
ISA 90X90X8 Steel Angles

Steel Type
Mild Steel / Structural Steel

Steel Product Type
Angle Bar / L-Angle

Grade
Available in IS 2062, E250, S275JR, or equivalent grades

Thickness
8 mm

Shape
L-shaped (Equal Angle)

Steel Standard
IS 2062 / ASTM A36 / EN 10025 or equivalent

Surface
Hot rolled, mill finish

Composition
Primarily iron, with carbon, manganese, and trace elements

Application
Structural support, construction frameworks, industrial fabrication, tower and bridge building

Dimension (L*W*H)
90 mm x 90 mm x 8 mm (Leg x Leg x Thickness)

Weight
Approximately 10.7 kg/meter

Color
Metallic grey

Material Grade
IS 2062 E250 / ASTM A36 / S275JR

Finish Type
Hot rolled, uncoated

Usage
Construction, support frames, industrial fabrication, machinery

Packing Type
Loose, bundle, or strapped as per customer needs

Delivery Condition
Straight, without bends or warping

Weldability
Excellent

Straightness Tolerance
1 mm per meter

Magnetic Properties
Ferromagnetic

Edge Condition
Square, as-rolled

Length Options
6 meters, 9 meters, 12 meters, or as per requirement

Temperature Range
-20C to 450C (service temperature)

Manufacturing Process
Hot rolled

Cutting Tolerance
2 mm

Storage Recommendations
Keep dry, covered, and off the ground

ISA 90X90X8 Steel Angles Trade Information

Minimum Order Quantity
100 Kilograms

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Kilograms Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About ISA 90X90X8 Steel Angles

Spotlight the paragon of structural integrity with ISA 90X90X8 Steel Angles-crafted to deliver meritorious performance in any application. Engineered from the finest mild structural steel, these angles feature hot rolled, uncoated, metallic grey surfaces and square edges for flawless weldability. Available lengths include 6, 9, or 12 meters, or you can order as per your exact requirement. Each piece comes straight and true, supporting up to 540 MPa tensile strength and enduring temperatures from -20C to 450C. Pick yours for projects that demand the highest standard in reliability and recyclability.

Exceptional Features & Directions for Use

ISA 90X90X8 Steel Angles boast excellent weldability, a straightness tolerance of 1 mm per meter, and a hot-rolled, square-edged finish-ideal for precision construction and industrial frameworks. This meritorious angle bar is suitable for structural support, bridge and tower building, as well as heavy machinery fabrication. To ensure optimal performance, store dry, covered, and elevated. Use as L-shaped bracing, load-bearing supports, or framework depending on your project's needs.

Global Export & Sample Policy

ISA 90X90X8 Steel Angles enjoy strong demand in the international market, with supply chains extending from India to multiple export destinations. Finished angles are securely handed over in packaging options like loose, bundled, or strapped-tailored to your shipment requirements. Samples are available upon request to validate quality and fit; sample policies are designed to ensure you confidently assess our finest product before large-scale orders.

FAQ's of ISA 90X90X8 Steel Angles:

Q: How should ISA 90X90X8 Steel Angles be stored before use?

A: Store these steel angles in a dry, covered location and off the ground to prevent corrosion and maintain their straightness and integrity until installation.

Q: What is the manufacturing process for ISA 90X90X8 Steel Angles?

A: These angles are produced using a hot rolling process, resulting in a strong, mill-finished product ideal for structural and industrial applications.

Q: Where can ISA 90X90X8 Steel Angles be used?

A: They are widely utilized in construction frameworks, industrial fabrications, support frames, machinery bases, tower and bridge building, and other structural applications.

Q: What are the benefits of using ISA 90X90X8 Steel Angles?

A: Engineered for superior weldability, moderate corrosion resistance, and high tensile strength, they provide reliable support in demanding environments and are fully recyclable.

Q: How are the angles delivered and what packaging options are available?

A: The angles are supplied straight-with no bends-and can be delivered loose, in bundles, or strapped, depending on your specific packaging requirements.
